Polar Switch
Independent power supply, perfect solution for 120 live-only wiring switches.
Pollar Switch adopts extremely low power consumption technology and independent power supply. It supports single live line, null and live line and low direct current (≤ 30V). It eliminates the flicker when a traditional single live line switch is connected to a low power light bulb, providing an easy solution for installation and use.
Download Intructions
Share:
Description
FEATURES
- No flicker, safe and stable
- No need for external wiring
- Dual control, multiple control
- LED indicator
SPECFICATION
| General | |
| Control Unit | 16A magnetic latching relay |
| Operating Temperature | -5~45°C |
| Operating Humidity | 5~90% |
| Power Supply | AC 100-240V 50/60Hz |
| Static Consumption | <1mW |
| Maximum Overload | Resistive load: 500W (one way) Capacitive/Reductive load: 200W (one way) |
| Battery Type | ER18505M(CR17505、ER17505) |
| Battery Life | 5 years |
| Construction | |
| Color | White |
| Dimension | 120*70*35mm |
| Casing | ABS+PC |
| Radio | |
| Radio Protocol | CoSS |
| Signal Range (Open Field) | 200m |
| Polar Switch (1 way) | |
| Model Number | LS211 |
| Wiring | Live only / Live+neutral |
| Weight | 141g |
| Polar Switch (2 way) | |
| Model Number | LS212 |
| Wiring | Live only / Live+neutral |
| Weight | 152g |
| Polar Switch (3 way) | |
| Model Number | LS213 |
| Wiring | Live only / Live+neutral |
| Weight | 163g |
| Polar Multi-control Accessory | |
| Model Number | LS214 |
| Wiring | No wiring
|
| Weight | 120g |
